#I2S on 2.0.0-alpha.175 causing panic
Thread channel in help
Rikke
Rikke 03/18/2025 11:20 AM
I have updated my toit sdk to 175, and I have changed the use of I2S to match the new syntax:
i2s_bus = i2s.Bus --tx=pin --sample_rate=100_000 --bits_per_sample=32 --buffer_size=(buf.size + reset.size) --use-apll=false
to
i2s_bus = i2s.Bus --master=true --mclk=null --tx=pin --sck=null --ws=null i2s_bus.configure --sample_rate=100_000 --bits_per_sample=32 i2s_bus.start
But in 1 out of 20 reboots(ish) I get a panic when starting up the i2s:
Guru Meditation Error: Core 1 panic'ed (Cache disabled but cached memory region accessed). Core 1 register dump: PC : 0x400d5904 PS : 0x00060035 A0 : 0x80088c96 A1 : 0x3ffb2b50 A2 : 0x3ffd48e8 A3 : 0x3ffb2b70 A4 : 0x3ffd4810 A5 : 0x3ffaf960 A6 : 0x00000003 A7 : 0x00060723 A8 : 0x80080eef A9 : 0x00060923 A10 : 0x3ffd4810 A11 : 0x00000002 A12 : 0x00000000 A13 : 0x3ffb4484 A14 : 0x00000001 A15 : 0x3ffafa84 SAR : 0x00000001 EXCCAUSE: 0x00000007 EXCVADDR: 0x00000000 LBEG : 0x00000000 LEND : 0x00000000 LCOUNT : 0x00000000 ******************************************* Decoding by `jag`, device has version <2.0.0-alpha.175> ******************************************* Crash in native code: Backtrace: 0x400d5901:0x3ffb2b50 0x40088c93:0x3ffb2b70 0x40087079:0x3ffb2bb0 0x40089b39:0x3ffb2bd0 0x4008544a:0x3ffaf9b0 0x4008558b:0x3ffaf9d0 0x400d5901: toit::primitive_toit_callback_deinit(toit::Process*, toit::Object**) + 0x15 0x40088c93: i2s_dma_rx_callback + 0x8b 0x40087079: esp_random + 0x15 0x40089b39: interrupt_hlevel_restore + 0x11 0x4008544a: spi_flash_disable_cache$constprop$0 + 0x6 0x4008558b: spi_flash_guard_set + 0x3 *******************************************

I am using i2s_bus.write to write to the pin. It works fine most of the time, but am I starting up the I2S too early?
floitsch
floitsch 03/18/2025 11:26 AM
Not good...
floitsch
floitsch 03/18/2025 11:26 AM
I'm having a look.
floitsch
floitsch 03/18/2025 11:27 AM
Are you sure it's during startup?
floitsch
floitsch 03/18/2025 11:27 AM
(there is a deinit-callback)
Rikke
Rikke 03/18/2025 11:28 AM
I am not 100% sure no, but I can try and reproduce with more debugging messages
floitsch
floitsch 03/18/2025 11:28 AM
The ideal would be something I can reproduce, but I'm looking at the code too.
floitsch
floitsch 03/18/2025 11:28 AM
Could also be that the stacktrace isn't correct.
floitsch
floitsch 03/18/2025 11:28 AM
I don't see how the dma_rx_callback can call the deinit.
floitsch
floitsch 03/18/2025 11:29 AM
Do you have external (spiram) ram?
Rikke
Rikke 03/18/2025 11:29 AM
That is possible, I have problems with building jag. It does not put the sdk under .cache/jaguar so i move it manually. I am not using external spiram
Rikke
Rikke 03/18/2025 11:29 AM
So maybe its using default sdk
floitsch
floitsch 03/18/2025 11:30 AM
Ok. So this is on a standard esp32 without any spiram.
Rikke
Rikke 03/18/2025 11:30 AM
Correct
floitsch
floitsch 03/18/2025 11:32 AM
Looking at the error message it's likely I forgot to add an IRAM attribute.
floitsch
floitsch 03/18/2025 11:32 AM
Do you build your envelope yourself, or do you use a published one?
Rikke
Rikke 03/18/2025 11:32 AM
I am building myself
floitsch
floitsch 03/18/2025 11:33 AM
Ok. In that case try to disable I2S_ISR_IRAM_SAFE.
Rikke
Rikke 03/18/2025 11:34 AM
I2S INIT 1 I2S INIT 2 I2S INIT 3 I2S INIT 4 debug: (1970-01-01T00:00:00Z) Watchdog: started led_control Guru Meditation Error: Core 0 panic'ed (Cache disabled but cached memory region accessed). Core 0 register dump: PC : 0x400d5904 PS : 0x00060035 A0 : 0x80088c96 A1 : 0x3ffb2550 A2 : 0x3ffd4900 A3 : 0x3ffb2570 A4 : 0x3ffd4828 A5 : 0x3ffaf3d0 A6 : 0x00000003 A7 : 0x00060f23 A8 : 0x80080eef A9 : 0x00060123 A10 : 0x3ffd4828 A11 : 0x00000002 A12 : 0x00000000 A13 : 0x3ffb4484 A14 : 0x00000000 A15 : 0x3ffaf4f4 SAR : 0x0000001b EXCCAUSE: 0x00000007 EXCVADDR: 0x00000000 LBEG : 0x4000c46c LEND : 0x4000c477 LCOUNT : 0xffffffff ****************************************************************************** Decoding by `jag`, device has version <2.0.0-alpha.175> ****************************************************************************** Crash in native code: Backtrace: 0x400d5901:0x3ffb2550 0x40088c93:0x3ffb2570 0x40087079:0x3ffb25b0 0x40089b39:0x3ffb25d0 0x40085450:0x3ffaf420 0x4008558b:0x3ffaf440 0x400d5901: toit::primitive_toit_callback_deinit(toit::Process*, toit::Object**) + 0x15 0x40088c93: i2s_dma_rx_callback + 0x8b 0x40087079: esp_random + 0x15 0x40089b39: interrupt_hlevel_restore + 0x11 0x40085450: spi_flash_disable_cache$constprop$0 + 0xc 0x4008558b: spi_flash_guard_set + 0x3 ******************************************************************************
so after init 4
print "I2S INIT 1" i2s_bus = i2s.Bus --master=true --mclk=null --tx=pin --sck=null --ws=null print "I2S INIT 2" i2s_bus.configure --sample_rate=100_000 --bits_per_sample=32 print "I2S INIT 3" i2s_bus.start print "I2S INIT 4"
before i start writing
floitsch
floitsch 03/18/2025 11:35 AM
I'm pretty sure the crash happens because the interrupt is trying to call one of our callbacks, but that callback isn't in IRAM.
floitsch
floitsch 03/18/2025 11:35 AM
I need to find the place where I forgot the IRAM attribute.
Rikke
Rikke 03/18/2025 11:35 AM
I will rebuild and try to reproduce
๐Ÿ™1
floitsch
floitsch 03/18/2025 11:36 AM
If you disable I2S_ISR_IRAM_SAFE you tell the esp-idf that it shouldn't call the callback when it might not be in IRAM. So in theory that should work around the issue.
floitsch
floitsch 03/18/2025 11:39 AM
I just realized I have an appointment in a few minutes.
I will be (mostly) offline, but once I come back I will look into this.
Rikke
Rikke 03/18/2025 11:39 AM
Its fine, i will just test this for now
๐Ÿ‘1
Rikke
Rikke 03/18/2025 12:09 PM
I have not been able to reproduce the error, but I got another panic now :๐Ÿ™ˆ: looks like i got error messages when trying to configure, and the panic itself before starting the i2s.

I2S INIT 1 I2S INIT 2 E (26638) i2s_common: i2s_alloc_dma_desc(431): allocate DMA buffer failed E (26638) i2s_std: i2s_std_set_slot(106): allocate memory for dma descriptor failed E (26638) i2s_std: i2s_channel_init_std_mode(217): initialize channel failed while setting slot I2S INIT 3 Guru Meditation Error: Core 1 panic'ed (LoadProhibited). Exception was unhandled. Core 1 register dump: PC : 0x401005ca PS : 0x00060030 A0 : 0x801012c2 A1 : 0x3ffc5da0 A2 : 0x3ffebe50 A3 : 0xffffffff A4 : 0x0000000a A5 : 0x00000000 A6 : 0x00000000 A7 : 0x3ffefc84 A8 : 0x3ff4f000 A9 : 0x00000000 A10 : 0x00000000 A11 : 0x00000002 A12 : 0x00060020 A13 : 0x00060023 A14 : 0x3ffaeb6c A15 : 0x3ffb01b8 SAR : 0x00000010 EXCCAUSE: 0x0000001c EXCVADDR: 0x00000000 LBEG : 0x4000c349 LEND : 0x4000c36b LCOUNT : 0xffffffff
Rikke
Rikke 03/18/2025 12:09 PM
************* Decoding by `jag`, device has version <2.0.0-alpha.175> ************* Crash in native code: Backtrace: 0x401005c7:0x3ffc5da0 0x401012bf:0x3ffc5dc0 0x400d5bfe:0x3ffc5df0 0x40081d3e:0x3ffc5e10 0x400f2771:0x3ffc5ea0 0x400f29f1:0x3ffc5ef0 0x400f2a11:0x3ffc5f20 0x400e58fa:0x3ffc5f40 0x400e5921:0x3ffc5f60 0x401005c7: nvs::Storage::writeItem(unsigned char, nvs::ItemType, char const*, void const*, unsigned int) + 0x13 0x401012bf: nvs::NVSPartitionManager::init_partition(char const*) + 0x53 0x400d5bfe: toit::primitive_set_characteristic_notify(toit::Process*, toit::Object**) + 0x4e 0x40081d3e: toit::Interpreter::run() + 0x9e6 0x400f2771: toit::primitive_region_open(toit::Process*, toit::Object**) + 0xd5 0x400f29f1: toit::primitive_partition_find(toit::Process*, toit::Object**) + 0x161 0x400f2a11: toit::primitive_region_is_erased(toit::Process*, toit::Object**) + 0xd 0x400e58fa: toit::FlashRegistry::write_chunk(void const*, int, int) + 0x1e 0x400e5921: toit::FlashRegistry::find_next(int, LinkedList<toit::Reservation, 1>::Iterator*) + 0x9 *************
Rikke
Rikke 03/18/2025 12:10 PM
It looks like a out of memory issue, but it shouldnt really cause a panic. I got a OOM message right before this, 55k free with largest free being 16k (trying to connect to MQTT with TLS)
RikkeOPRikke
I have not been able to reproduce the error, but I got another panic now :๐Ÿ™ˆ: looks like i got error messages when trying to configure, and the panic itself before starting the i2s....
floitsch
floitsch 03/18/2025 01:53 PM
Basically, we are sometimes running out of DMA buffers.
floitsch
floitsch 03/18/2025 01:53 PM
So far we have only seen this from the wifi-stack, which made it really hard to investigate, as that code is closed source.
floitsch
floitsch 03/18/2025 01:54 PM
Seeing a similar error in a different part of the system is interesting.
floitsch
floitsch 03/18/2025 01:57 PM
Do you think the stacktrace is trustworthy?
Could you try to decode it with the SDK that you used to build your envelope?
echo Backtrace: 0x401005c7:0x3ffc5da0 0x401012bf:0x3ffc5dc0 0x400d5bfe:0x3ffc5df0 0x40081d3e:0x3ffc5e10 0x400f2771:0x3ffc5ea0 0x400f29f1:0x3ffc5ef0 0x400f2a11:0x3ffc5f20 0x400e58fa:0x3ffc5f40 0x400e5921:0x3ffc5f60 | build/host/sdk/tools/stacktrace build/esp32/toit.elf
Rikke
Rikke 03/18/2025 01:58 PM
I have not been able to reproduce the dma/oom error since I posted the last message. I will try and decode
Rikke
Rikke 03/18/2025 01:58 PM
echo Backtrace: 0x401005c7:0x3ffc5da0 0x401012bf:0x3ffc5dc0 0x400d5bfe:0x3ffc5df0 0x40081d3e:0x3ffc5e10 0x400f2771:0x3ffc5ea0 0x400f29f1:0x3ffc5ef0 0x400f2a11:0x3ffc5f20 0x400e58fa:0x3ffc5f40 0x400e5921:0x3ffc5f60 | build/host/sdk/tools/stacktrace build/esp32/toit.elf 0x401005c7: i2s_tx_channel_start + 0xb3 0x401012bf: i2s_channel_enable + 0x7f 0x400d5bfe: toit::primitive_start(toit::Process*, toit::Object**) + 0x5a 0x40081d3e: toit::Interpreter::run() + 0xa42 0x400f2771: toit::Scheduler::run_process(toit::Locker&, toit::Process*, toit::SchedulerThread*) + 0x5d 0x400f29f1: toit::Scheduler::run(toit::SchedulerThread*) + 0x5d 0x400f2a11: toit::SchedulerThread::entry() + 0x9 0x400e58fa: toit::Thread::_boot() + 0x22 0x400e5921: toit::esp_thread_start(void*) + 0x5
floitsch
floitsch 03/18/2025 01:59 PM
Perfect. Thanks. That makes much more sense.
Rikke
Rikke 03/18/2025 01:59 PM
Yeah as i thought. The jaguar sdk is not the correct one
floitsch
floitsch 03/18/2025 01:59 PM
The DMA error is something we have been chasing, but so far has elluded us. I also have a small hope that upgrading the ESP-IDF to an even newer version could help.
Unfortunately, we don't know when it will get fixed.
floitsch
floitsch 03/18/2025 01:59 PM
But with your error report we have a new angle to look at it.
Rikke
Rikke 03/18/2025 02:00 PM
I did the same for first panic message:
echo Backtrace: 0x400d5901:0x3ffb2b50 0x40088c93:0x3ffb2b70 0x40087079:0x3ffb2bb0 0x40089b39:0x3ffb2bd0 0x4008544a:0x3ffaf9b0 0x4008558b:0x3ffaf9d0 | build/host/sdk/tools/stacktrace build/esp32/toit.elf 0x400d5901: toit::I2sResource::adjust_pending_event(int) + 0x9 0x40088c93: i2s_dma_tx_callback + 0x4f 0x40087079: shared_intr_isr + 0x35 0x40089b39: _xt_lowint1 + 0x89 0x4008544a: spi_flash_op_block_func + 0x22 0x4008558b: ipc_task + 0x53
floitsch
floitsch 03/18/2025 02:00 PM
ah nice.
floitsch
floitsch 03/18/2025 02:00 PM
Thanks.
RikkeOPRikke
It looks like a out of memory issue, but it shouldnt really cause a panic. I got a OOM message right before this, 55k free with largest free being 16k (trying to connect to MQTT wi...
floitsch
floitsch 03/18/2025 02:08 PM
do you still have the message?
it shouldn't matter, but just in case.
Rikke
Rikke 03/18/2025 02:09 PM
I do not :๐Ÿ˜ฆ:
floitsch
floitsch 03/18/2025 02:09 PM
np.
Rikke
Rikke 03/18/2025 02:10 PM
Okay but I just got the same i2s dma buffer alloc error again, this time without any OOM messages
floitsch
floitsch 03/18/2025 02:10 PM
ok. good to know.
floitsch
floitsch 03/18/2025 02:10 PM
out of curiosity: what are you using the i2s for?
Rikke
Rikke 03/18/2025 02:11 PM
To control our leds, we ran out of UARTs
floitsch
floitsch 03/18/2025 02:12 PM
is it the pixel-strip?(edited)
Rikke
Rikke 03/18/2025 02:13 PM
Yes
Rikke
Rikke 03/18/2025 02:13 PM
W2812B
floitsch
floitsch 03/18/2025 02:13 PM
how many leds do you have there?
Rikke
Rikke 03/18/2025 02:14 PM
We are using 4, but they always use same color all 4 of them
floitsch
floitsch 03/18/2025 02:16 PM
I wonder if we could use the RMT peripheral or the SPI interface instead.
Clearly, we need to fix this, but it might be an easy work-around for now.
floitsch
floitsch 03/18/2025 02:16 PM
I will continue looking, but if I can't find anything soon (within a day or so), I might write an RMT/SPI version.
floitsch
floitsch 03/18/2025 02:16 PM
Do you use the RMT for anything so far?
floitsch
floitsch 03/18/2025 02:17 PM
(it is used behind your back for the DHT11, and one-wire bus)
Rikke
Rikke 03/18/2025 02:17 PM
Its not really a rush for us, we turn off the leds after 2 minutes anyway, so its only really a problem when it boots. But boot time is super quick anyway
floitsch
floitsch 03/18/2025 02:18 PM
good to know.
As I said: having crashes is really not nice, so we do want to fix this.
If it ever becomes more urgent to you, please ping us. It is already relatively high priority, but still.
Rikke
Rikke 03/18/2025 02:19 PM
Yes I fully understand, but you dont have to write another driver for this, unless its a big issue for other people ofc
floitsch
floitsch 03/18/2025 02:19 PM
Shouldn't be too hard and a challenge that sounds fun. But yes; I probably have other things to do :๐Ÿ™‚:
floitsch
floitsch 03/19/2025 11:40 AM
@Rikke : I couldn't resist. I just released a new version of the pixel-strip package that supports RMT. I think it should work nicely with the few pixels you have.(edited)
๐Ÿ‘Œ1
bitphlipphar
bitphlipphar 03/19/2025 12:13 PM
@floitsch I think there is a missing null check here: https://github.com/toitware/esp-idf/blob/patch-head-5.3.1/components/esp_driver_i2s/i2s_common.c#L419. Could that explain the crash if we're really unlucky?
Espressif IoT Development Framework. Official development framework for ESP32. - toitware/esp-idf
bitphlipphar
bitphlipphar 03/19/2025 12:24 PM
Espressif IoT Development Framework. Official development framework for Espressif SoCs. - Issues ยท espressif/esp-idf
bitphlipphar
bitphlipphar 03/19/2025 02:16 PM
@Rikke We've just released v2.0.0-alpha.176 with a few fixes. There still may be more work for us, but we wanted to make the new bits available as quickly as possible :๐Ÿ™‚:(edited)
Rikke
Rikke 03/20/2025 07:30 AM
Thanks :๐Ÿ™‚: will try the new release today
๐Ÿ‘1
Rikke
Rikke 03/24/2025 12:20 PM
Looks like espressif added your line for null check, but I am still able to reproduce the panic when using I2S. I did not notice you've already added the line in alpha 176, so we might have to swap LED driver for now
bitphlipphar
bitphlipphar 03/24/2025 12:22 PM
Yeah, it was a bit of a long shot - and I wasn't convinced that it would solve the issue. More work for us, but do give the RMT-based LED driver a spin :๐Ÿ™‚:
๐Ÿ‘Œ1
RikkeOPRikke
Looks like espressif added your line for null check, but I am still able to reproduce the panic when using I2S. I did not notice you've already added the line in alpha 176, so we m...
floitsch
floitsch 03/24/2025 12:23 PM
Is the stack trace still the same?
Rikke
Rikke 03/24/2025 12:24 PM
I tried to decode but it cant find the xtensa-esp32-elf-objdump

echo Backtrace: 0x40101b83:0x3ffc3da0 0x4010294b:0x3ffc3dc0 0x400d5d32:0x3ffc3df0 0x40081d86:0x3ffc3e10 0x400f299d:0x3ffc3ea0 0x400f2c1d:0x3ffc3ef0 0x400f2c3d:0x3ffc3f20 0x400e5b3e:0x3ffc3f40 0x400e5b65:0x3ffc3f60 | build/host/sdk/tools/stacktrace build/esp32/toit.elf EXCEPTION error. Error trying to run 'xtensa-esp32-elf-objdump' using $PATH: No such file or directory: xtensa-esp32-elf-objdump 0: decode-stacktrace /home/vsts/staging/toit/tools/stacktrace.toit:66:5 1: build-command.<lambda> /home/vsts/staging/toit/tools/stacktrace.toit:38:16 2: Command.run.<block> <pkg:pkg-cli>/cli.toit:308:40 3: Parser_.parse <pkg:pkg-cli>/parser_.toit:212:5 4: Command.run <pkg:pkg-cli>/cli.toit:306:12 5: main /home/vsts/staging/toit/tools/stacktrace.toit:27:7
Rikke
Rikke 03/24/2025 12:25 PM
But i am getting the same errors from i2s driver:
E (3711657) i2s_common: i2s_alloc_dma_desc(432): allocate DMA buffer failed E (3711657) i2s_std: i2s_std_set_slot(106): allocate memory for dma descriptor failed E (3711667) i2s_std: i2s_channel_init_std_mode(217): initialize channel failed while setting slot
Rikke
Rikke 03/24/2025 12:30 PM
Okay i rebuild, reflashed and reproduced:
echo Backtrace: 0x40101b83:0x3ffc5da0 0x4010294b:0x3ffc5dc0 0x400d5d32:0x3ffc5df0 0x40081d86:0x3ffc5e10 0x400f299d:0x3ffc5ea0 0x400f2c1d:0x3ffc5ef0 0x400f2c3d:0x3ffc5f20 0x400e5b3e:0x3ffc5f40 0x400e5b65:0x3ffc5f60 | build/host/sdk/tools/stacktrace build/esp32/toit.elf 0x40101b83: i2s_tx_channel_start + 0xb3 0x4010294b: i2s_channel_enable + 0x7b 0x400d5d32: toit::primitive_start(toit::Process*, toit::Object**) + 0x5a 0x40081d86: toit::Interpreter::run() + 0xa42 0x400f299d: toit::Scheduler::run_process(toit::Locker&, toit::Process*, toit::SchedulerThread*) + 0x5d 0x400f2c1d: toit::Scheduler::run(toit::SchedulerThread*) + 0x5d 0x400f2c3d: toit::SchedulerThread::entry() + 0x9 0x400e5b3e: toit::Thread::_boot() + 0x22 0x400e5b65: toit::esp_thread_start(void*) + 0x5
Same error as before
(edited)
floitsch
floitsch 03/24/2025 12:35 PM
Thanks
Rikke
Rikke 03/24/2025 12:47 PM
Well. I added a info log message when allocating the 6 DMA buffers, to check if its the first, last or just random buffer that fails. And so far I have not been able to reproduce :๐Ÿ™ƒ: I am printing the info log messages to console(edited)
Rikke
Rikke 03/24/2025 12:51 PM
Now Ive written 50 times in a row with no errors, I wonder if its a weird yield issue
floitsch
floitsch 03/24/2025 12:51 PM
How did you instrument the code?
Rikke
Rikke 03/24/2025 12:53 PM
I added ESP_LOGI(TAG, "DMA malloc info: dma_desc_num = %d", i); right before the line ESP_GOTO_ON_FALSE(handle->dma.bufs[i], ESP_ERR_NO_MEM, err, TAG, "allocate DMA buffer failed"); in the file third_party/esp-idf/components/esp_driver_i2s/i2s_common.c and rebuild, reflash and command the device to write to the LEDs with i2s over and over again
floitsch
floitsch 03/24/2025 12:54 PM
weird. Clearly that should not change whether the thing crashes or not.
There is, of course, the possibility that cache lines are different, changing the timing, but I would hope that doesn't matter that much.
Rikke
Rikke 03/24/2025 12:55 PM
Its really odd yes..
RikkeOPRikke
Its really odd yes..
bitphlipphar
bitphlipphar 03/24/2025 01:01 PM
Can you share the build/esp32/toit.elf file with me somehow? I'd like to take a look at the assembly code around 0x40101b83.
Rikke
Rikke 03/24/2025 01:03 PM
How do you want me to send it to you?
bitphlipphar
bitphlipphar 03/24/2025 01:03 PM
Email perhaps? Maybe it is so big that I'll need to download it from somewhere?
Rikke
Rikke 03/24/2025 01:04 PM
20M hmm
Rikke
Rikke 03/24/2025 01:06 PM
Looks like I can send it over mail
Rikke
Rikke 03/24/2025 01:07 PM
Do you have a support mail?
floitsch
floitsch 03/24/2025 01:07 PM
Just send it to [email protected]
๐Ÿ‘1
Rikke
Rikke 03/24/2025 01:09 PM
Ah okay, it got decliend because it is too big
Rikke
Rikke 03/24/2025 01:12 PM
The .zip mightve worked
bitphlipphar
bitphlipphar 03/24/2025 01:12 PM
Got it! Thanks :๐Ÿ™‚:
bitphlipphar
bitphlipphar 03/24/2025 01:17 PM
Found the load that is causing the crash. Now I have to try to figure out what it corresponds to in the C++ code :๐Ÿ™‚:
bitphlipphar
bitphlipphar 03/24/2025 01:17 PM
Good fun on a Monday!
๐Ÿ˜…1
Rikke
Rikke 03/24/2025 01:20 PM
Okay I was finally able to make it crash with info log message, and it crashed when allocating the 3rd dma buffer :๐Ÿคท:
I (285857) i2s_common: DMA malloc info: dma_desc_num = 0 I (285857) i2s_common: DMA malloc info: dma_desc_num = 1 I (285857) i2s_common: DMA malloc info: dma_desc_num = 2 E (285857) i2s_common: i2s_alloc_dma_desc(433): allocate DMA buffer failed E (285867) i2s_std: i2s_std_set_slot(106): allocate memory for dma descriptor failed E (285877) i2s_std: i2s_channel_init_std_mode(217): initialize channel failed while setting slot
(edited)
floitsch
floitsch 03/24/2025 01:38 PM
And then crashed immediately afterwards?
Rikke
Rikke 03/24/2025 01:38 PM
Yes, it always crashes after the 3 i2s errors
floitsch
floitsch 03/24/2025 01:39 PM
Kasper is already looking into the esp-idf to figure out where they don't handle null-pointers correctly.
floitsch
floitsch 03/24/2025 01:39 PM
Normally, when the esp-idf can't allocate something it returns with an ERR_NO_MEM (or something like that).
floitsch
floitsch 03/24/2025 01:39 PM
The Toit VM then does a GC and tries again.
floitsch
floitsch 03/24/2025 01:40 PM
However, here the ESP_IDF isn't return correctly, and we don't get a chance to do any GC.
floitsch
floitsch 03/24/2025 01:40 PM
For most users this isn't really an issue, since they can't do anything once the memory is tight.
floitsch
floitsch 03/24/2025 01:40 PM
It's mostly interesting for systems that actually can find memory somewhere, like the Toit VM.
floitsch
floitsch 03/24/2025 01:41 PM
We have plans to do a GC immediately inside a malloc, so that bugs like these don't affect the Toit VM, but that requires some refactoring in our primitives.
๐Ÿ‘1
bitphlipphar
bitphlipphar 03/24/2025 02:51 PM
So the crash is definitely loading from dma.desc even though it is NULL. Maybe there is a missing failure check in the code that calls i2s_alloc_dma_desc, so it still tries to start the tx even though it is out of memory.
bitphlipphar
bitphlipphar 03/25/2025 06:37 AM
I think I've found another subtle bug in esp-idf.
bitphlipphar
bitphlipphar 03/25/2025 06:42 AM
/* The DMA buffer need to re-allocate if the buffer size changed */ if (handle->dma.buf_size != buf_size) { handle->dma.buf_size = buf_size; ESP_RETURN_ON_ERROR(i2s_free_dma_desc(handle), TAG, "failed to free the old dma descriptor"); ESP_RETURN_ON_ERROR(i2s_alloc_dma_desc(handle, handle->dma.desc_num, buf_size), TAG, "allocate memory for dma descriptor failed"); }
bitphlipphar
bitphlipphar 03/25/2025 06:43 AM
It seems completely broken to update handle->dma.buf_size before making sure that the allocations succeed. If we fail the allocation and retry, we will not try to re-allocate the structures.
bitphlipphar
bitphlipphar 03/25/2025 06:52 AM
bitphlipphar
bitphlipphar 03/25/2025 07:12 AM
Will try to patch this in our own fork of the esp-idf and get a new build out.
Rikke
Rikke 03/25/2025 08:09 AM
Nice job! I can try and patch myself to test
bitphlipphar
bitphlipphar 03/25/2025 08:09 AM
You probably only need the changes in i2s_std.c.(edited)
bitphlipphar
bitphlipphar 03/25/2025 08:11 AM
You should still expect to see the error logs (E (285857) i2s_common: i2s_alloc_dma_desc(433): allocate DMA buffer failed), but at least now there should be a chance that it will not lead to a crash on the retry.
Rikke
Rikke 03/25/2025 08:11 AM
Okay so move the size change till after it has been allocated
bitphlipphar
bitphlipphar 03/25/2025 08:12 AM
/* The DMA buffer need to re-allocate if the buffer size changed */ if (handle->dma.buf_size != buf_size) { - handle->dma.buf_size = buf_size; ESP_RETURN_ON_ERROR(i2s_free_dma_desc(handle), TAG, "failed to free the old dma descriptor"); ESP_RETURN_ON_ERROR(i2s_alloc_dma_desc(handle, handle->dma.desc_num, buf_size), TAG, "allocate memory for dma descriptor failed"); + handle->dma.buf_size = buf_size; }
๐Ÿ‘Œ1
bitphlipphar
bitphlipphar 03/25/2025 08:12 AM
Yes.
Rikke
Rikke 03/25/2025 08:36 AM
I still got a panic :/
Rikke
Rikke 03/25/2025 08:37 AM
Same errors, same backtrace
bitphlipphar
bitphlipphar 03/25/2025 08:38 AM
Probably just means more work for me, but can you post your git diff from the esp-idf directory? :๐Ÿ™‚:
Rikke
Rikke 03/25/2025 08:39 AM
Yes let me clean up some logs and reproduce again
Rikke
Rikke 03/25/2025 08:42 AM
diff --git a/components/esp_driver_i2s/i2s_common.c b/components/esp_driver_i2s/i2s_common.c index ca7332e32..695a7a30e 100644 --- a/components/esp_driver_i2s/i2s_common.c +++ b/components/esp_driver_i2s/i2s_common.c @@ -417,7 +417,7 @@ esp_err_t i2s_alloc_dma_desc(i2s_chan_handle_t handle, uint32_t num, uint32_t bu handle->dma.desc = (lldesc_t **)heap_caps_calloc(num, sizeof(lldesc_t *), I2S_MEM_ALLOC_CAPS); ESP_GOTO_ON_FALSE(handle->dma.desc, ESP_ERR_NO_MEM, err, TAG, "create I2S DMA descriptor array failed"); handle->dma.bufs = (uint8_t **)heap_caps_calloc(num, sizeof(uint8_t *), I2S_MEM_ALLOC_CAPS); - ESP_GOTO_ON_FALSE(handle->dma.bufs, ESP_ERR_NO_MEM, err, TAG, "create I2S DMA buffers array failed"); + ESP_GOTO_ON_FALSE(handle->dma.bufs, ESP_ERR_NO_MEM, err, TAG, "create I2S DMA buffer array failed"); for (int i = 0; i < num; i++) { /* Allocate DMA descriptor */ handle->dma.desc[i] = (lldesc_t *) i2s_dma_calloc(handle, 1, sizeof(lldesc_t));
Rikke
Rikke 03/25/2025 08:42 AM
@@ -429,6 +429,7 @@ esp_err_t i2s_alloc_dma_desc(i2s_chan_handle_t handle, uint32_t num, uint32_t bu handle->dma.desc[i]->size = bufsize; handle->dma.desc[i]->offset = 0; handle->dma.bufs[i] = (uint8_t *) i2s_dma_calloc(handle, 1, bufsize * sizeof(uint8_t)); + // ESP_LOGI(TAG, "DMA malloc info: dma_desc_num = %d", i); ESP_GOTO_ON_FALSE(handle->dma.bufs[i], ESP_ERR_NO_MEM, err, TAG, "allocate DMA buffer failed"); #if SOC_CACHE_INTERNAL_MEM_VIA_L1CACHE esp_cache_msync(handle->dma.bufs[i], bufsize * sizeof(uint8_t), ESP_CACHE_MSYNC_FLAG_DIR_C2M); diff --git a/components/esp_driver_i2s/i2s_std.c b/components/esp_driver_i2s/i2s_std.c index c3ef0c046..878b1845c 100644 --- a/components/esp_driver_i2s/i2s_std.c +++ b/components/esp_driver_i2s/i2s_std.c @@ -101,10 +101,10 @@ static esp_err_t i2s_std_set_slot(i2s_chan_handle_t handle, const i2s_std_slot_c uint32_t buf_size = i2s_get_buf_size(handle, slot_cfg->data_bit_width, handle->dma.frame_num); /* The DMA buffer need to re-allocate if the buffer size changed */ if (handle->dma.buf_size != buf_size) { - handle->dma.buf_size = buf_size; ESP_RETURN_ON_ERROR(i2s_free_dma_desc(handle), TAG, "failed to free the old dma descriptor"); ESP_RETURN_ON_ERROR(i2s_alloc_dma_desc(handle, handle->dma.desc_num, buf_size), TAG, "allocate memory for dma descriptor failed"); + handle->dma.buf_size = buf_size; } bool is_slave = handle->role == I2S_ROLE_SLAVE; /* Share bck and ws signal in full-duplex mode */
bitphlipphar
bitphlipphar 03/25/2025 08:43 AM
Yeah, I just found another bug.
Rikke
Rikke 03/25/2025 08:43 AM
Another one okay
bitphlipphar
bitphlipphar 03/25/2025 08:44 AM
So i2s_alloc_dma_desc updates buf_size too and it does it wrong.
bitphlipphar
bitphlipphar 03/25/2025 08:51 AM
esp_err_t i2s_free_dma_desc(i2s_chan_handle_t handle) { I2S_NULL_POINTER_CHECK(TAG, handle); + uint32_t desc_num = handle->dma.desc_num; + + handle->dma.desc_num = 0; + handle->dma.buf_size = 0; + if (!handle->dma.desc) { return ESP_OK; } - for (int i = 0; i < handle->dma.desc_num; i++) { + for (int i = 0; i < desc_num; i++) { if (handle->dma.bufs[i]) {
bitphlipphar
bitphlipphar 03/25/2025 08:52 AM
That is my next attempt. Also I'm dropping all the updates to buf_size outside of i2s_alloc_dma_desc, but I don't think it matters much.
Rikke
Rikke 03/25/2025 08:54 AM
Testing changes to free dma desc
Rikke
Rikke 03/25/2025 08:55 AM
E (971) i2s_common: i2s_alloc_dma_desc(423): create I2S DMA descriptor array failed E (971) i2s_std: i2s_std_set_slot(105): allocate memory for dma descriptor failed E (971) i2s_std: i2s_channel_init_std_mode(217): initialize channel failed while setting slot E (981) i2s_common: i2s_alloc_dma_desc(423): create I2S DMA descriptor array failed E (991) i2s_std: i2s_std_set_slot(105): allocate memory for dma descriptor failed E (1001) i2s_std: i2s_channel_init_std_mode(217): initialize channel failed while setting slot E (1011) i2s_common: i2s_alloc_dma_desc(423): create I2S DMA descriptor array failed E (1011) i2s_std: i2s_std_set_slot(105): allocate memory for dma descriptor failed E (1021) i2s_std: i2s_channel_init_std_mode(217): initialize channel failed while setting slot
Rikke
Rikke 03/25/2025 08:55 AM
Heap report @ out of memory in primitive 7:2: โ”Œโ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”ฌโ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”ฌโ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ” โ”‚ Bytes โ”‚ Count โ”‚ Type โ”‚ โ”œโ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”ผโ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”ผโ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”ค โ”‚ 8 โ”‚ 1 โ”‚ external byte array โ”‚ โ”‚ 32768 โ”‚ 10 โ”‚ toit processes โ”‚ โ”‚ 16384 โ”‚ 4 โ”‚ system 0 ba2bb6f3-b6cd-d9c6-621d-7632ae3d2f0c โ”‚ โ”‚ 16384 โ”‚ 4 โ”‚ current 1 8de635b4-126e-3003-f980-e3a3ec6281c5 โ”‚ โ”‚ 20480 โ”‚ 1 โ”‚ heap metadata โ”‚ โ”‚ 4096 โ”‚ 1 โ”‚ spare new-space โ”‚ โ”‚ 5352 โ”‚ 13 โ”‚ lwip โ”‚ โ”‚ 4720 โ”‚ 326 โ”‚ heap overhead โ”‚ โ”‚ 2104 โ”‚ 33 โ”‚ event source โ”‚ โ”‚ 9424 โ”‚ 126 โ”‚ thread/other โ”‚ โ”‚ 26400 โ”‚ 21 โ”‚ thread/spawn โ”‚ โ”‚ 22696 โ”‚ 100 โ”‚ untagged โ”‚ โ””โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”ดโ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”ดโ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”˜ Total: 128048 bytes in 304 allocations (43%), largest free 108k, total free 165k E (1201) i2s_common: i2s_alloc_dma_desc(423): create I2S DMA descriptor array failed E (1211) i2s_std: i2s_std_set_slot(105): allocate memory for dma descriptor failed E (1221) i2s_std: i2s_channel_init_std_mode(217): initialize channel failed while setting slot
Rikke
Rikke 03/25/2025 08:58 AM
diff --git a/components/esp_driver_i2s/i2s_common.c b/components/esp_driver_i2s/i2s_common.c index ca7332e32..f0fd7483f 100644 --- a/components/esp_driver_i2s/i2s_common.c +++ b/components/esp_driver_i2s/i2s_common.c @@ -380,10 +380,15 @@ uint32_t i2s_get_buf_size(i2s_chan_handle_t handle, uint32_t data_bit_width, uin esp_err_t i2s_free_dma_desc(i2s_chan_handle_t handle) { I2S_NULL_POINTER_CHECK(TAG, handle); + uint32_t desc_num = handle->dma.desc_num; + + handle->dma.desc_num = 0; + handle->dma.buf_size = 0; + if (!handle->dma.desc) { return ESP_OK; } - for (int i = 0; i < handle->dma.desc_num; i++) { + for (int i = 0; i < desc_num; i++) { if (handle->dma.bufs[i]) { free(handle->dma.bufs[i]); handle->dma.bufs[i] = NULL;
bitphlipphar
bitphlipphar 03/25/2025 08:58 AM
So no crash in native code?
Rikke
Rikke 03/25/2025 08:58 AM
Nope
Rikke
Rikke 03/25/2025 08:59 AM
****************************************************************************** Decoding by `jag`, device has version <2.0.0-alpha.176> ****************************************************************************** MALLOC_FAILED error. 0: Bus.configure <sdk>/i2s.toit:475:5 1: LedI2S /home/vsts/--/src/i2s_led_driver.toit:96:13 2: led-task /home/vsts/--/src/led_handler.toit:91:13 3: setup-gpio /home/vsts/--/src/pinout.toit:130:5 4: main /home/vsts/--/src/gateway.toit:25:3 ******************************************************************************

but reset because of [toit] WARN: entering deep sleep for 1s due to error
(edited)
bitphlipphar
bitphlipphar 03/25/2025 09:00 AM
That is progress!
๐Ÿฅณ1
bitphlipphar
bitphlipphar 03/25/2025 09:05 AM
Now we have to figure out why the three attempts to initialize the i2s subsystem with GCs in between isn't enough to make this work.
Rikke
Rikke 03/25/2025 09:10 AM
But it fails on i2s.bus configure now, not i2s.bus start like before
Rikke
Rikke 03/25/2025 09:11 AM
And it crashed when trying to start a i2s.bus with dma allocation fail
floitsch
floitsch 03/25/2025 09:12 AM
Does your code (up to this point) depend on specific hardware?
floitsch
floitsch 03/25/2025 09:12 AM
Or do you think we could maybe reproduce it locally?
Rikke
Rikke 03/25/2025 09:14 AM
Should be easy to reproduce locally, i set up the i2s:
i2s_bus = i2s.Bus --master=true --mclk=null --tx=pin --sck=null --ws=null i2s_bus.configure --sample_rate=100_000 --bits_per_sample=32 i2s_bus.start

and write written := i2s_bus.write buf.copy + reset.copy
RikkeOPRikke
But it fails on i2s.bus configure now, not i2s.bus start like before
bitphlipphar
bitphlipphar 03/25/2025 09:14 AM
Yeah, so we now notice that we failed to allocate the buffers, so the primitive fails. Before it would claim to succeed leading to a crash down the line.
bitphlippharbitphlipphar
Yeah, so we now notice that we failed to allocate the buffers, so the primitive fails. Before it would claim to succeed leading to a crash down the line.
Rikke
Rikke 03/25/2025 09:14 AM
Ah true
RikkeOPRikke
Should be easy to reproduce locally, i set up the i2s: ``` i2s_bus = i2s.Bus --master=true --mclk=null --tx=pin --sck=null --ws=null i2s_bus....
floitsch
floitsch 03/25/2025 09:14 AM
Is that all you do?
no other hardware/drivers started before?
Rikke
Rikke 03/25/2025 09:15 AM
Its a part of our code, but I can see if I can run and reproduce on a simple esp devkit
Rikke
Rikke 03/25/2025 09:16 AM
import i2s import bytes import gpio import encoding.hex import system.storage
the imports we use for driver
floitsch
floitsch 03/25/2025 09:18 AM
Interesting. I did a lot of i2s tests, but never encountered this error. That said, I never used 100_000 samples. So maybe that's why.
I just assumed it was dependent on other code you had run before. I will give it a try in a few minutes and see if I can reproduce.
Rikke
Rikke 03/25/2025 09:20 AM
Hm not sure how to flash a dev kit through jag with my own build sdk
floitsch
floitsch 03/25/2025 09:20 AM
You need to have a local checkout of Jaguar.
Rikke
Rikke 03/25/2025 09:21 AM
When building jag it does not put in the sdk under .cache
floitsch
floitsch 03/25/2025 09:21 AM
But let me test first. If I can reproduce you don't need to go through the trouble.
floitsch
floitsch 03/25/2025 09:21 AM
If you have a local Jaguar, you need to set JAG_TOIT_REPO_PATH to the root of the SDK checkout
floitsch
floitsch 03/25/2025 09:22 AM
Then you can just make and it also builds the envelope.
Rikke
Rikke 03/25/2025 09:23 AM
This is our jag build command JAG_TOIT_REPO_PATH=~/staging/toit make -C staging/jaguar JAG_BUILD_RELEASE=1(edited)
floitsch
floitsch 03/25/2025 09:23 AM
bitphlipphar
bitphlipphar 03/25/2025 09:24 AM
You probably don't want to pass JAG_BUILD_RELEASE=1 because that will give you a binary that only looks in ~/.cache/ if I am not mistaken.
Rikke
Rikke 03/25/2025 09:24 AM
Ah okay, will try without
RikkeOPRikke
Should be easy to reproduce locally, i set up the i2s: ``` i2s_bus = i2s.Bus --master=true --mclk=null --tx=pin --sck=null --ws=null i2s_bus....
floitsch
floitsch 03/25/2025 09:49 AM
looks like that on its own isn't enough.
floitsch
floitsch 03/25/2025 09:49 AM
import i2s import bytes import gpio import encoding.hex import system.storage main: pin := gpio.Pin 32 i2s_bus := i2s.Bus --master=true --mclk=null --tx=pin --sck=null --ws=null i2s_bus.configure --sample_rate=100_000 --bits_per_sample=32 i2s_bus.start bytes := ByteArray 1024 i2s_bus.write bytes
Rikke
Rikke 03/25/2025 09:50 AM
We open it everytime we write and close it again afterwards
Rikke
Rikke 03/25/2025 09:51 AM
So everytime we write to the leds. we have to open the i2s.bus and that means allocating the 6 dma buffers
floitsch
floitsch 03/25/2025 09:52 AM
This is my code now:
import i2s import bytes import gpio import encoding.hex import system.storage main: while true: pin := gpio.Pin 32 i2s_bus := i2s.Bus --master=true --mclk=null --tx=pin --sck=null --ws=null i2s_bus.configure --sample_rate=100_000 --bits_per_sample=32 i2s_bus.start bytes := ByteArray 1024 i2s_bus.write bytes i2s_bus.stop i2s_bus.close pin.close
Still no crash.
Rikke
Rikke 03/25/2025 09:54 AM
Dont know if its a actual memory issue, because we have high traffic in our dev area that has to be passed and sent on mqtt. This often leads to low memory so bad timing is prob what causes the allocation error
Rikke
Rikke 03/25/2025 09:56 AM
Not sure what other drivers are using dma
floitsch
floitsch 03/25/2025 09:56 AM
could be general memory pressure as well.
Rikke
Rikke 03/25/2025 09:57 AM
I tried following the other thread and the jaguar github but it wont work. heres a attempt to jag flash
Error: Failed to open '' for reading (FILE_NOT_FOUND: ""). Error: exit status 1
JAG_TOIT_REPO_PATH=/home/vsts/staging/toit
(edited)
floitsch
floitsch 03/25/2025 09:58 AM
can you show a bit more output (the lines before).
Rikke
Rikke 03/25/2025 09:59 AM
vsts@rikke:~/staging/jaguar$ build/jag flash Enter WiFi network (SSID): WiFi_QA_3 Enter WiFi password for 'WiFi_QA_3': Error: Failed to open '' for reading (FILE_NOT_FOUND: ""). Error: exit status 1
floitsch
floitsch 03/25/2025 09:59 AM
That just seems to indicate that it doesn't find the usb-port
floitsch
floitsch 03/25/2025 10:01 AM
btw: if you are frequently flashing, you can avoid typing the wifi credentials by
build/jag config wifi set --wifi-password="WiFi_QA_3" --wifi-ssid="WiFi_QA_3"
Rikke
Rikke 03/25/2025 10:01 AM
Odd when jag monitor works
bitphlipphar
bitphlipphar 03/25/2025 10:01 AM
Could be that you can't find the tools for flashing.
floitsch
floitsch 03/25/2025 10:02 AM
that's right. you might not have esptool.py where we try to find it.
floitsch
floitsch 03/25/2025 10:04 AM
Kasper and I have the esptool.py in our PATH.
floitsch
floitsch 03/25/2025 10:04 AM
Try to source the export.sh from the esp-idf.
Rikke
Rikke 03/25/2025 10:04 AM
I will add that to the build process
Rikke
Rikke 03/25/2025 10:05 AM
This docker container does not have access to esptool.py i think
floitsch
floitsch 03/25/2025 10:05 AM
Since you are on Windows, you might need export.bat.
Rikke
Rikke 03/25/2025 10:06 AM
I am on linux
floitsch
floitsch 03/25/2025 10:06 AM
No idea where I got that from. Sorry.
Then source $JAG_TOIT_REPO_PATH/third_party/esp-idf/export.sh should do it.
Rikke
Rikke 03/25/2025 10:09 AM
Okay it is there ./toit/third_party/esp-idf/components/esptool_py/esptool/esptool.pybut its not added with the exports.. Guess i will manually add it
floitsch
floitsch 03/25/2025 10:10 AM
weird. For me it added it.
floitsch
floitsch 03/25/2025 10:11 AM
แ… source ../opentoit/third_party/esp-idf/export.sh Setting IDF_PATH to '/home/flo/work/opentoit/third_party/esp-idf' ... แ… which esptool.py /home/flo/.espressif/python_env/idf5.3_py3.13_env/bin/esptool.py
Rikke
Rikke 03/25/2025 10:13 AM
Yeah I just give up :๐Ÿ™ƒ:
floitsch
floitsch 03/25/2025 10:13 AM
no worries :๐Ÿ™‚:
floitsch
floitsch 03/25/2025 10:59 AM
[jaguar] INFO: program cbaa7f18-0910-cf8a-ed22-16dbb4a5f3b7 started E (9020) i2s_common: i2s_alloc_dma_desc(432): allocate DMA buffer failed E (9020) i2s_std: i2s_std_set_slot(106): allocate memory for dma descriptor failed E (9020) i2s_std: i2s_channel_init_std_mode(217): initialize channel failed while setting slot Guru Meditation Error: Core 0 panic'ed (LoadProhibited). Exception was unhandled. Core 0 register dump: PC : 0x40105292 PS : 0x00060930 A0 : 0x80106092 A1 : 0x3ffd1da0 A2 : 0x3ffef9f8 A3 : 0xffffffff A4 : 0x00000000 A5 : 0x00000000 A6 : 0x00000000 A7 : 0x3fff547c A8 : 0x3ff4f000 A9 : 0x00000000 A10 : 0x00000000 A11 : 0x00000002 A12 : 0x00060920 A13 : 0x00060923 A14 : 0x00000001 A15 : 0x3ffbdd28 SAR : 0x00000018 EXCCAUSE: 0x0000001c EXCVADDR: 0x00000000 LBEG : 0x4000c349 LEND : 0x4000c36b LCOUNT : 0xffffffff ****************************************************************************** Decoding by `jag`, device has version <2.0.0-alpha.176.4+floitsch-i2c.registers.slave.a63ae902> ****************************************************************************** Crash in native code: Backtrace: 0x4010528f:0x3ffd1da0 0x4010608f:0x3ffd1dc0 0x400d99f6:0x3ffd1df0 0x40081e72:0x3ffd1e10 0x400f63d4:0x3ffd1ea0 0x400f665d:0x3ffd1ef0 0x400f667d:0x3ffd1f20 0x400e97c6:0x3ffd1f40 0x400e97ed:0x3ffd1f60 0x4010528f: i2s_tx_channel_start + 0xb3 0x4010608f: i2s_channel_enable + 0x7f
First step in reproducing.
This is still without Kasper's patch.
bitphlipphar
bitphlipphar 03/25/2025 10:59 AM
Nice!
floitsch
floitsch 03/25/2025 11:02 AM
I'm just running a second container that does https stuff in a loop.
floitsch
floitsch 03/25/2025 11:09 AM
[jaguar] INFO: program 5243ce0f-2715-f465-ab36-1119f0d306ca started E (54350) i2s_common: i2s_alloc_dma_desc(422): create I2S DMA descriptor array failed E (54350) i2s_std: i2s_std_set_slot(105): allocate memory for dma descriptor failed E (54350) i2s_std: i2s_channel_init_std_mode(216): initialize channel failed while setting slot E (54370) i2s_common: i2s_alloc_dma_desc(422): create I2S DMA descriptor array failed E (54370) i2s_std: i2s_std_set_slot(105): allocate memory for dma descriptor failed E (54370) i2s_std: i2s_channel_init_std_mode(216): initialize channel failed while setting slot E (54390) i2s_common: i2s_alloc_dma_desc(422): create I2S DMA descriptor array failed E (54400) i2s_std: i2s_std_set_slot(105): allocate memory for dma descriptor failed E (54400) i2s_std: i2s_channel_init_std_mode(216): initialize channel failed while setting slot Heap report @ out of memory in primitive 7:2: โ”Œโ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”ฌโ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”ฌโ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ” ... โ””โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”ดโ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”ดโ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”€โ”˜ Total: 198768 bytes in 475 allocations (83%), largest free 24k, total free 42k E (54610) i2s_common: i2s_alloc_dma_desc(422): create I2S DMA descriptor array failed E (54610) i2s_std: i2s_std_set_slot(105): allocate memory for dma descriptor failed E (54620) i2s_std: i2s_channel_init_std_mode(216): initialize channel failed while setting slot ****************************************************************************** Decoding by `jag`, device has version <2.0.0-alpha.176.5+f1a00000> ****************************************************************************** MALLOC_FAILED error. 0: Bus.configure <sdk>/i2s.toit:473:5 1: main /home/flo/tmp/i2s-dma/main.toit:18:13 ******************************************************************************
I can reproduce.
Rikke
Rikke 03/25/2025 11:15 AM
So it is also related to low memory
floitsch
floitsch 03/25/2025 11:28 AM
Or memory pressure
floitsch
floitsch 03/25/2025 11:28 AM
And memory churn
bitphlipphar
bitphlipphar 03/25/2025 11:40 AM
One theory is that it is two containers that fight for the same memory, unable to coordinate their efforts well enough.
Rikke
Rikke 03/25/2025 11:40 AM
Okay a rebuild of jag without release flag fixed all my problems. stacktrace is now correct and I can use jag flash :๐Ÿ‘:
๐Ÿ‘1
bitphlippharbitphlipphar
One theory is that it is two containers that fight for the same memory, unable to coordinate their efforts well enough.
Rikke
Rikke 03/25/2025 11:56 AM
We are only running 2 containers, the "system" and our program
RikkeOPRikke
We are only running 2 containers, the "system" and our program
bitphlipphar
bitphlipphar 03/25/2025 12:22 PM
So the MQTT activity is from the same container that tries to use the LEDs via I2S?
Rikke
Rikke 03/25/2025 12:23 PM
Yes, we run everything from same container. We are starting a new container for modem connectivity, but I am currently testing on wifi
RikkeOPRikke
Yes, we run everything from same container. We are starting a new container for modem connectivity, but I am currently testing on wifi
bitphlipphar
bitphlipphar 03/25/2025 12:33 PM
That's good news. I think that will make it easier for us to debug and fix.
bitphlipphar
bitphlipphar 03/25/2025 03:34 PM
Looks like we found and fixed the issue.
bitphlipphar
bitphlipphar 03/26/2025 11:20 AM
@Rikke Let me know if you're able to update to HEAD of the master branch and try the fix:๐Ÿคž:

I'll be preparing a new SDK release if things look good to you.
Rikke
Rikke 03/26/2025 11:26 AM
I would have to manually patch it with the changes in the commit above, our build system is based on specific sdk versions, gonna test it now
bitphlipphar
bitphlipphar 03/26/2025 11:27 AM
Thank you!
bitphlipphar
bitphlipphar 03/26/2025 11:28 AM
My original fix made the i2s subsystem ask for zero bytes on retry (a clear bug) and the allocator always responds with null in that case. When the allocator returns null, we assume we're out of memory and try to clean up and retry, but we just kept asking for zero bytes repeatedly thus eventually concluding that there was no memory left. Woops.(edited)
Rikke
Rikke 03/26/2025 11:29 AM
Haha :๐Ÿ˜„:
Rikke
Rikke 03/26/2025 11:39 AM
It no longer panics on i2s error!
E (13649) i2s_common: i2s_alloc_dma_desc(434): allocate DMA buffer failed E (13649) i2s_std: i2s_std_set_slot(106): allocate memory for dma descriptor failed E (13659) i2s_std: i2s_channel_init_std_mode(217): initialize channel failed while setting slot E (13669) i2s_common: i2s_alloc_dma_desc(434): allocate DMA buffer failed E (13669) i2s_std: i2s_std_set_slot(106): allocate memory for dma descriptor failed E (13679) i2s_std: i2s_channel_init_std_mode(217): initialize channel failed while setting slot
no reset
(edited)
bitphlipphar
bitphlipphar 03/26/2025 11:40 AM
So it works better for you?
Rikke
Rikke 03/26/2025 11:40 AM
Yes, im pretty sure it just retries because leds are correct after error
bitphlipphar
bitphlipphar 03/26/2025 11:40 AM
I get the feeling you don't like panics :๐Ÿ˜…:
floitsch
floitsch 03/26/2025 11:41 AM
fwiw, I would still switch to the RMT implementation. It should use less memory for the 4 LEDs.
Rikke
Rikke 03/26/2025 11:42 AM
It wasnt really a problem until i tested on our other devices. We have a device controlling machinery by toggling a relay, and we light up when we are controlling. This device might end up in a restart loop because it restarts and toggles led to indicate its controlling etc
floitschfloitsch
fwiw, I would still switch to the RMT implementation. It should use less memory for the 4 LEDs.
Rikke
Rikke 03/26/2025 11:42 AM
I did notice that. I like the RMT implementation
๐Ÿ‘1
Rikke
Rikke 03/26/2025 11:45 AM
I would 100% prefer just retrying instead of full chip reboot, and I am sure I am not the only one :๐Ÿ™‚:
211 messages in total
