Looping MALLOC_FAILED in jaguar

Toit

#Looping MALLOC_FAILED in jaguar

Thread channel in help

addshore 09/05/2025 04:58 PM

I got this looping MALLOC_FAILED in jaguar today, while not really running anything else on the device

[jaguar] WARN: running Jaguar failed due to 'MALLOC_FAILED' (2/3)
[jaguar.http] INFO: running Jaguar device 'long-expert' (id: '736b8804-dcdf-4d96-890a-8785c1bfa31d') on 'http://192.168.68.50:9000'
Heap report @ out of memory in primitive 3:4:
  ┌───────────┬──────────┬─────────────────────────────────────────────────────┐
  │   Bytes   │  Count   │  Type                                               │
  ├───────────┼──────────┼─────────────────────────────────────────────────────┤
  │    7400   │    728   │  heap overhead                                      │
  │  258064   │    691   │  untagged                                           │
  └───────────┴──────────┴─────────────────────────────────────────────────────┘
  Total: 265464 bytes in 691 allocations (81%), largest free 44k, total free 62k
[jaguar] WARN: running Jaguar failed due to 'MALLOC_FAILED' (3/3)
[jaguar] INFO: backing off for 5s

addshore 09/05/2025 04:58 PM

ultimately lead to a device crash

addshore 09/05/2025 04:59 PM

I possibly could have been trying to do a wifi scan, however I imagine that would have imediatly failed and shouldnt be an issue

floitsch 09/06/2025 11:40 AM

Primitive 3:4 is UDP-Send.
It's likely the Jaguar broadcast failed.
Given that you have sufficient memory, my guess is that something internal went bad and reported a memory-failure even though that's not exactly what happened.
For now there is little to go on. If we see this more frequently we need to investigate.

addshore 09/09/2025 09:30 AM

the udp broadcast is pretty frequent from memory?
Does it have limitations in terms of one at a time, and timeout for an attempt?

floitsch 09/09/2025 09:31 AM

There is a loop that broadcasts every few ms. That should be sequential.
The underlying network should be able to handle multiple requests (potentially by blocking, but I don't know exactly).

addshore 09/11/2025 10:18 AM

Getting more things like this while running different code on my side

[jaguar] WARN: running Jaguar failed due to 'MALLOC_FAILED' (2/3)
[jaguar.http] INFO: running Jaguar device 'national-diamond' (id: '94879073-44c2-49d1-b1d3-650a4d37c067') on 'http://192.168.1.107:9000'
Heap report @ out of memory in primitive 3:4:
  ┌───────────┬──────────┬─────────────────────────────────────────────────────┐
  │   Bytes   │  Count   │  Type                                               │
  ├───────────┼──────────┼─────────────────────────────────────────────────────┤
  │    7808   │    778   │  heap overhead                                      │
  │  251640   │    737   │  untagged                                           │
  └───────────┴──────────┴─────────────────────────────────────────────────────┘
  Total: 259448 bytes in 737 allocations (79%), largest free 28k, total free 68k
[wifi] DEBUG: closing
fatal: esp_event_handler_unregister(base, id, on_event)

addshore 09/11/2025 10:19 AM

Which ultimately lead to a crash

floitsch 09/11/2025 10:22 AM

I will have a look at the code and see if there is something that sticks out.

addshore 09/11/2025 11:32 AM

i think it is likely while doing a ble scan and or a wifi scan at the same time as jaguar trying to do its thing

floitsch 09/11/2025 11:32 AM

good to know.

floitsch 09/11/2025 11:32 AM

if you have something that is (mostly) reproducible, that could help.

addshore 09/11/2025 11:37 AM

I wonder if https://github.com/lightbug-io/toit-lightbug/blob/94f6469f588ef1f7f14ae2c131ca457f1cda536b/examples/modules/ble/advanced.toit works out of the box without one of our devices
I think it should / might just work on any ESP
But we are specificaly on a C6

toit-lightbug/examples/modules/ble/advanced.toit at 94f6469f588ef1f...

A Toit package for working with Lightbug devices in Toit - lightbug-io/toit-lightbug

addshore 09/11/2025 11:38 AM

i dont have "just" an esp32c6 here to try it on right now, but if it fails I can likely hack it to work

addshore 09/11/2025 11:39 AM

infact, if it fails, I think changing like 5 to be device := devices.Fake will mean it will work

addshore 09/11/2025 11:40 AM

Though that has gotten to scan #24 no issue
with the real device it died at #11
Which implies that it is the combination of this example code doing ble scans, but simultaniously in the background other code doing wifi and ble scans

addshore 09/11/2025 11:43 AM

Yes, so using Fake and also adding this before the loop in that code

task::
    while true:
      print "=== Background scans ==="
      sleep --ms=15000
      device.ble.scan --async --duration=3000
      sleep --ms=500
      device.wifi.scan --async --duration=3000

Makes it happen a bit

addshore 09/11/2025 11:44 AM

my main surprise is how it affects jaguar
However I'm also no acutely aware I should add some extra handling around my scans to make sure im not trying to do too much at once

floitsch 09/11/2025 11:46 AM

You could also remove the broadcasts

floitsch 09/11/2025 11:47 AM

You would then need to give the address to scan but that's not a big deal.

addshore 09/11/2025 11:48 AM

I was thinking that this is likely only an issue during development
And wondering if I could easily add a check. if jag, disable jag networking stuff for a second, do the scans, and turn it back on?

addshore 09/11/2025 11:48 AM

and tbh, i dont use the broadcasts from jag right now, always providing my specific --device

floitsch 09/11/2025 11:49 AM

Might as well disable them entirely. That's a flag I would accept for Jaguar

floitsch 09/11/2025 11:49 AM

--device

uses scan in the background. I wonder if that still works nicely.

addshore 09/11/2025 11:49 AM

well, im normally passing an IP to --device anyway

floitsch 09/11/2025 11:50 AM

Then definitely

addshore 09/11/2025 12:40 PM

i wonder if I should write these on github so i dont forget!

addshore 09/11/2025 12:46 PM

done for this one

https://github.com/toitlang/jaguar/issues/635

Feat: Add option to skip jaguar UDP broadcast · Issue #635 · toit...

Per discussion in https://discord.com/channels/918498540232253480/1413568907985420339 doing wifi scans and or bluetooth scans and result in errors relating to jaguar UDP broadcasts. [jaguar] WARN: ...
